Horizontal |
BF |
BA |
Remarques |
0 |
- |
82.5 |
A 23cm depuis la quille, tirer une
droite à 0,5 sur l'axe horizontal. |
0.5 |
0 |
- |
1.5 |
0 |
- |
2.5 |
- |
82.5 |
Courbe du Bord d'attaque jusqu'à
32.5 cm sur l'axe horizontal
|
5 |
3.4 |
31.9 |
10 |
8.8 |
80.5 |
15 |
13.3 |
79 |
20 |
16.9 |
77.4 |
25 |
20.1 |
75.7 |
30 |
22.7 |
73.7 |
32.5 |
- |
72.8 |
BA Droit jusqu'à 77 cm sur l'axe
horizontal
|
35 |
25 |
|
37 |
Tendeur |
|
40 |
26.8 |
|
44.7 |
Tendeur |
|
45 |
28.4 |
|
50 |
29.8 |
|
55 |
31 |
|
60 |
32 |
|
65 |
32.9 |
|
70 |
33.6 |
|
75 |
34.2 |
|
77 |
- |
55.7 |
BA Droit jusqu'à la pointe d'aile
|
80 |
34.8 |
|
85 |
35.1 |
|
90 |
35.3 |
|
95 |
35.2 |
|
100 |
35.1 |
|
105 |
34.8 |
|
110 |
34.3 |
|
115 |
33.6 |
|
120 |
32.7 |
|
125 |
31.5 |
|
130 |
30 |
|
133.3 |
29 |
|
134 |
- |
31.4 |
|
Bridage |
Incidence |
68cm |
Extérieure |
63cm |
Intérieure |
73cm |
Turbo |
n/a |
|
|
Structure: |
Spine |
Structil 6mm |
82.5cm |
BA |
Skyshark P300 |
145cm |
Vergues |
Skyshark P300 |
76cm |
Vergues |
Skyshark P300 |
74cm |
Topcross |
Structil 6mm
|
52cm |
standoff |
Carbone 3mm
|
26cm |
Distances |
Nez - APA topcross
|
32 cm
|
Nez - APA vergue
|
95cm |
Nez - APA vergue |
90.5cm |
Nez - bloque-yoyo |
55cm |
Nez - croix
|
55.5cm |
Nez - Croix |
52 |
La structure en P300 est plus réactive, je préfère....
Bridage revu et corrigé...
|
Updates: |
Bridage:
incidence |
52.5cm |
extérieure |
56cm |
intérieure |
65cm |
turbo |
4cm |
|
Structure:
Standoffs extérieurs |
27.5cm
|
|
|
|
|
|
|
|
|
